Specifications

• Engine

  add remove
  • Engine Type:
    Single-Cylinder
  • Engine:
    Standard
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    4
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    OHV
  • Bore (mm):
    96
  • Bore (in):
    3.78
  • Stroke (mm):
    71.5
  • Stroke (in):
    2.81
  • Displacement (cc):
    518
  • Displacement (ci):
    31.6
  • Fuel Type:
    Gas
  • Carburetion:
    Standard
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Parental Controls:
    Not Available
  • Speed Governor:
    No
  • Kill Switch / Tether Cord:
    Not Available
  • Engine Block Heater:
    Not Available
  • Fuel Injector Size (mm):
    36
  • Other Engine:
    Not Available
  • Compression Ratio:
    9.5:1
  • Starter:
    Electric
• PRICING

  add remove
  • Price:
    Standard
  • MSRP:
    9749
  • MSRP + Destination:
    10369
  • Currency:
    US Dollars
  • Warranty (Months):
    12
  • Warranty (Condition):
    Limited
  • Destination Charge:
    620
• TRANSMISSION

  add remove
  • Transmission:
    Standard
  • Transmission Type:
    Manual
  • Number Of Speeds:
    5
  • Primary Drive (Rear Wheel):
    Shaft
  • Reverse:
    Yes
  • Adjustable Throttle:
    Not Available
  • Primary Drive (Front Wheel):
    Shaft
  • Primary Drive (Engine / Transmission):
    Gear
  • Other Transmission:
    Not Available
• DRIVE LINE

  add remove
  • Driveline:
    Standard
  • Driveline Type:
    Selectable 4X2 / 4X4
  • Number Of Driveline Modes:
    3
  • Rear Unlocking Differential:
    No
  • Limited Slip Differential:
    Not Available
  • Differential Lock:
    Standard
  • Driveline Brand:
    TraxLok™
  • Differential Lock Location:
    Front
  • Other Drive Line:
    Not Available
• TECHNICAL SPECIFICATIONS

  add remove
  • Dimensions:
    Standard
  • Length (mm):
    2184.4
  • Width (in):
    47.4
  • Width (mm):
    1204
  • Height (in):
    48.7
  • Height (mm):
    1237
  • Wheelbase (in):
    50.9
  • Wheelbase (mm):
    1293
  • Turning Radius (ft):
    11.5
  • Ground Clearance (in):
    9.8
  • Ground Clearance (mm):
    249
  • Weight:
    Standard
  • Capacities:
    Standard
  • Fuel Capacity (gal):
    3.9
  • Fuel Capacity (l):
    14.8
  • Fuel Capacity Reserve (gal):
    1.3
  • Fuel Capacity Reserve (l):
    4.9
  • Performance:
    Standard
  • Towing Capacity (lbs):
    1322
  • Towing Capacity (kgs):
    600
  • Wet Weight (lbs):
    697
  • Wet Weight (kg):
    316.2
• SUSPENSION

  add remove
  • Front Suspension:
    Standard
  • Front Suspension Type:
    Independent Double Wishbone
  • Front Travel (in):
    7.3
  • Front Travel (mm):
    185.4
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Front Stabilizer Bar:
    No
  • Steering Damper:
    No
  • Rear Suspension:
    Standard
  • Rear Suspension Type:
    Independent Double A-Arm
  • Rear Suspension Material:
    Steel
  • Rear Travel (in):
    8.5
  • Rear Travel (mm):
    215.9
  • Rear Adjustable Shock / Spring Pre-Load:
    No
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    2
  • Rear Stabilizer Bar:
    No
  • Air Adjustable:
    No
  • Other Suspension:
    Not Available
• WHEELS & TIRES

  add remove
  • Wheels:
    Standard
  • Wheels Composition:
    Steel
  • Front Tire Diameter (in):
    25
  • Rear Tire Diameter (in):
    25
  • Tires:
    Standard
  • Tire Brand:
    Maxxis®
  • Front Tire Width:
    8
  • Front Wheel Diameter:
    12
  • Rear Tire Width:
    10
  • Rear Wheel Diameter:
    12
  • Front Tire (Full Spec):
    Maxxis® 25 x 8-12
  • Rear Tire (Full Spec):
    Maxxis® 25 x 10-12
  • Tire Chains:
    Not Available
  • Spare Tire:
    Not Available
  • Other Wheels & Tires:
    Not Available
• BRAKES

  add remove
  • Brakes:
    Standard
  • Front Brake Type:
    Dual Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc
  • Anti-Lock Brakes:
    Not Available
  • Parking Brake:
    Standard
  • Linked Brake System Front to Rear:
    Not Available
  • Engine Braking:
    Not Available
  • Regenerative Braking:
    Not Available
  • Regenerative Deceleration:
    Not Available
  • Front Brake Diameter (in):
    7.5
  • Front Brake Diameter (mm):
    190
  • Rear Brake Diameter (in):
    6.7
  • Rear Brake Diameter (mm):
    170
  • Other Brakes:
    Not Available
• TOWING & HAULING

  add remove
  • Front Hitch:
    Not Available
  • Rear Hitch:
    Standard
  • Draw Bar:
    Not Available
  • Tow Hook:
    Not Available
  • Trailer:
    Not Available
  • Winch:
    Optional
  • Roller Fairlead:
    Optional
  • Rear Hitch Type:
    Standard
  • Tilt:
    No
  • Removable Tailgate:
    No
  • Removable Sides:
    No
  • Other Towing & Hauling:
    Not Available
• SEATS

  add remove
  • Seat:
    Standard
  • Seat Type:
    One-Piece
  • Seat Location:
    Driver
  • Seat Material:
    Vinyl
  • Seat Specifications:
    Standard
  • Seat Height (in):
    36.4
  • Seat Height (mm):
    925
  • Number Of Seats:
    1
  • Detachable Passenger Seat:
    Not Available
  • Seat Backrest:
    Not Available
  • Grab Rail or Strap:
    Not Available
  • Heated Seat:
    Not Available
  • Backrest Logo Plate:
    No
  • Lumbar Adjustment:
    No
  • Other Seat:
    Not Available
